• Length = 4 feet
• Wing span = 8 feet
• Weight = 6 lbs
• Engine (electric) = Axi Brushless
• Flying Time = 55 minutes
• Surfaces = Rudder, elevator and ailerons
• Control = MicroPilot's MP2128^g autopilot with HORIZON^mp Ground Control Software with RC option
• Average Speed = 60 km/h
• Maximum Winds = 30 km/h
• Payload Capability = 5 ounces to 1 pound

MP2128^g installed and pre-programmed with capability to program your own flight plans. The MP-Vision^e features automatic flap management providing steep descent for superior landing capability.

Radio modem standard range 2.4 GHz or 915 MHz base and remote (2.5 mile range)

• Airframe
• MP2128^g autopilot with GPS Ublox 4 Hz update rate
• Radio modem standard range (2.4 GHz or 915 MHz)
• GPS receiver and antenna
• HORIZON^mp Version 3.2 Ground Control Software
• One set of lithium polymer batteries (4 packs)
• Manuals
• One year technical support
• Universal camera box for optional camera

Required equipment such as Radio Control (RC) items, laptop and camera are not included. These additional items must be purchased separate. Please request an “Additional Equipment List.”

A universal cameral box is included and a digital camera can be attached. Recommend the Pentax Optio models. The Pentax has an infrared sensor for the shutter which allows us to use an infrared L.E.D. switch to trigger the shutter through commands given by the autopilot. In addition, we have designed a universal camera box that attaches securely to the wing and is held on by elastics bands. The camera and universal camera box together weigh five ounces (145 grams).

With the MP-Vision^e you have the option to develop and integrate you own sensor or camera.

RC Control

• RC Transmitter and receiver can be purchased locally for warranty and frequency purposes

Carrying Case

A carrying case can be purchased locally at Sporting Goods stores. Dimensions, 5.75 in (d), 12.75 in (w) and 51.5 in (l).

See www.cropcam.com for information about this product's applications in agriculture.
